Procesor DAP-Audio DSM-26 MKII 6 Canale

Procesor Audio Digital 2 intrari 6 iesiri, DSP: 96 kHz, 32 bits floating point DSP, 192 kHz AD/DA Converters: 24 bitsInput gain: -80dB – +12dB, step @ 0,1 dB, Input Impedance: Balanced 20kohm, Output gain: -80dB – +12dB, step @ 0,1 dB, Output Impedance: Balanced 100ohm, CMRR: >70dB@1kHz, Input range: ≤ ±25 dBu, Frequency response: 20Hz – 20kHz ±0,5dB, S/NR: >110dB, THD: <0,01% @output=0dBu/1kHz, Crosstalk: >80dB@1kHz, 6-Bands Input EQ, Bandwidth: 0,05 to 3 octaves in 0,05 octave steps, EQ gain control: -20 dB to +20 dB, EQ frequencies: 19,7Hz to 20kHz in 1/24 octave steps, Delay Input delay: Channel independent from 0 to 1000 mS, Output delay: Channel independent from 0 to 1000 mS, 6-Bands Output EQ, Type: Low Shelf, High Shelf and Parametric, Lo/High shelf slope: 6 dB/12 dB, EQ Bandwidth: 0,05 to 3 octaves in 0,05 steps. EQ gain control: -20 dB to +20 dB on al EQ types. EQ frequencies: 19,7 Hz to 20 kHz in 1/24 octave steps Crossovers, Types: Linkwitz Riley, Bessel and Butterworth, Slopes: 12, 18, 24, 30, 36, 42, 48 dB/octave, Frequencies: 19,7 Hz to 20 kHz in 1/24 octave steps, Limiter, Threshold points: -40 to +20 dBu in 0,5 dB steps, Attack times: 0,3 mS to 200 mS, Attack time steps: 0,1 mS steps from 0,3 to 1 mS, 1 mS steps from 1 to 100 mS, Release times: 50 ms – 5000 ms, Miscellaneous: Memory Storage: 30 User presets Display: 2x 24 dot matrix characters Latency: 2,61 mS USB Interface: 1x Front RS-485 interface: 2x Back Power Supply: 110/220 Volt AC, 50/60 Hz Power Consumption: 25 Watt Fuse: F0,5A/250V Dimensions: 482 x 44 x 192 mm(WxHxD) Net weight: 3,4 kg Accessories: Power-cable, USB cable, Software
